Total Cores 6

# of Performance-cores6

# of Efficient-cores0

Total Threads 12

Max Turbo Frequency 4.40 GHz

Performance-core Max Turbo Frequency 4.40 GHz

Performance-core Base Frequency2.50 GHz

Cache 18 MB Intel® Smart Cache

Total L2 Cache7.5 MB

Processor Base Power 65 W

Maximum Turbo Power 117 W

Supplemental Information

Embedded Options Available No

Memory Specifications

Max Memory Size (dependent on memory type) 128 GB

Memory Types Up to DDR5 4800 MT/s

Up to DDR4 3200 MT/s

Max # of Memory Channels 2

Max Memory Bandwidth 76.8 GB/s

Processor Graphics

Processor Graphics ‡ Intel® UHD Graphics 730

Graphics Base Frequency 300 MHz

Graphics Max Dynamic Frequency 1.45 GHz

Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1

Execution Units 24

Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz

Max Resolution (DP)‡ 7680 x 4320 @ 60Hz

Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz

DirectX* Support 12

OpenGL* Support 4.5

Multi-Format Codec Engines 1

Intel® Quick Sync Video Yes

Intel® Clear Video HD Technology Yes

# of Displays Supported ‡4

Device ID0x4692 / 0x4682

OpenCL* Support 2.1

Expansion Options

Direct Media Interface (DMI) Revision4.0

Max # of DMI Lanes8

Scalability1S Only

PCI Express Revision 5.0 and 4.0

PCI Express Configurations ‡ Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes 20

Package Specifications

Max CPU Configuration1

Thermal Solution Specification PCG 2020C

TJUNCTION 100°C

Package Size45.0 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator 3.0

Intel® Thread DirectorNo

Intel® Deep Learning Boost (Intel® DL Boost) Yes

Intel® Optane™ Memory Supported ‡ Yes

Intel® Speed Shift Technology Yes

Intel® Turbo Boost Max Technology 3.0 ‡ No

Intel® Turbo Boost Technology ‡ 2.0

Intel® Hyper-Threading Technology ‡ Yes

Intel® Virtualization Technology (VT-x) ‡ Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes

Intel® VT-x with Extended Page Tables (EPT) ‡ Yes

Intel® 64 ‡ Yes

Instruction Set 64-bit

Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States Yes

Enhanced Intel SpeedStep® Technology Yes

Thermal Monitoring Technologies Yes

Intel® Volume Management Device (VMD) Yes

Security & Reliability

Intel® AES New Instructions Yes

Secure Key Yes

Intel® OS GuardYes

Execute Disable Bit ‡ Yes

Intel® Boot Guard Yes

Mode-based Execute Control (MBE) Yes

Intel® Control-Flow Enforcement Technology Yes
